DESCALER

  1. Inhibit a formation of waterscale in pipes and apparatuses.
  2. Disintegrate old limescale deposits.
  3. Prevent to decreasing of heat exchange efficiency due the limescale formation, optimize energy costs.
  4. Constrain an inner surface corrosion of ferrous parts.
  5. Minimize maintenance expenses and increase the service life of pipe-lines and appliances, retrench the down time costs.
  6. Decrease a consumption of detergents and agents for chemical softening of water.


Advantages

  1. Easy installation without participation of pipers and electricians.
  2. Equipment selectivity for industrial and home applications.
  3. Mininization of flow cross section and head loss.
  4. Unchanged chemical composition and constant calcium content of treated water.
  5. Environmental-friendly operation without using any chemicals.
  6. Long service life without any maintenance work.
  7. Low power consumption, minimal costs of operation.
  8. Fast return of investment

DESCALERR - how it works

Our microprocessor based device DESCALER creates a frequency-modulated electromagnetic field in the supply pipes and forces calcium carbonate that is dissolved in the water to crystallize in the form of aragonite that does not form scale and is simply carried out of the system. Hard water treated this way acquires the properties of soft water and can dissolve already existing scale.


high frequency modulated electric field
 principle of electronic protection against scale
aragonite crystals with low adhesivity to any surface and therefore do not forming hard scale
incoming water saturated with calcium and other mineral ions
signal cable coiled externally around pipe
solution less saturated with calcium and able to dissolve existing scale













The DESCALER PS models protect technology systems against waterscale formation. The descaler can be installed on all types of pipes (steel, copper, plastic). When treating water of up to 90°C and hardness over 20°dH, in order to increase the effects of treatment it is recommended to use a plastic insert in the place of coil installation. The pipe diameter is a crucial parameter for choosing the right model of device. All devices are with external mains adapter.













Pipe I.D.
Flowrate
Dimension
Model
[inch (mm)]
[m3/h]
[W x H x D]
DESCALER PS 50
2" (50)
0.20 - 21.00
230 x 180 x 105
DESCALER PS 65
2,5" (65)
0.30 - 36.00
230 x 180 x 105
DESCALER PS 100
4" (100)
0.80 - 85.00
275 x 220 x 155
DESCALER PS 150
6" (150)
1.70 - 190.00
275 x 220 x 155
DESCALER PS 200
8" (200)
2.30 - 250.00
275 x 220 x 155
DESCALER PS 300
12" (300)
4.00 - 400.00
275 x 220 x 155

Technical specifications:
Power supply Mains adapter 230 V AC / 12 V DC 100 mA, stabilised
Alarm when out of order Audible warning signal
Capable of driving 2 coils in series
Enclosure material Uninflammable ABS, light grey
Maximum enclosure temperature 167°F, 75°C
Minimum enclosure temperature -22°F, -30°C
Signal intensity control Four level switch
Status LED indicator Red light - run
Red blinking - failure, disconnected coil circuit
Signal
Complex triangular frequency and amplitude modulated signal

Markets:
  • hotels, bars, restaurants, sauna
  • laundries, buildings, bakeries protecting cooling towers, boilers, heat exchangers, chillers commercial swimming pools
  • factories
